WMR-017 CVBS
Wemaer
*Camera style optional:500+ camera style
The function of the rearview mirror camera is to capture images of the rear of the vehicle and transmit the image signal to the internal central control display screen for display, so that the driver can clearly and unobstructedly view the traffic conditions behind the vehicle, providing safer driving assistance for the driver.
Facilitate drivers to have a clear and unobstructed view of the traffic behind the vehicle, creating a more comfortable and safe driving experience.
| Image Sensor | C030 1/6.25" CMOS | Resolution | 480 TV lines |
| TV System | NTSC/PAL | Sensing area | 3.030*2.725mm |
| Sync System | internal | Video output | 1.0Vp-p, 75Ω |
| Minimum illumination | 0.5Lux | Electronic shutter | Auto |
| White balance | Auto | S/N ratio | Better than 40dB |
| IR LEDs | No | Lens angle | 85 degree |
| Video color | Colorful | Operation temperature | -20° ~+70° |
| Waterproof class | IP68 | Storage temperature | -30° ~+80° |
| Effective pixels | 640(H)*480(V) | Warranty | 12 months |
