WMR-009 CVBS
Wemaer
*Camera style optional:500+ camera style
If your partner prefers a beautiful and simple installation, you can only install a reverse camera when installing the parking assist device, which can help you reverse.
If your partner has sufficient driving experience, they are quite accustomed to using the rearview mirror when reversing. He hopes to have an alarm to help park the car. If reverse radar is selected, the distance can be controlled through the buzzer alarm of the reverse radar.
For novice drivers, driving skills are not very sufficient. When dual protection is required, a reverse radar and reverse camera can be installed, making it safer to reverse.
| Image Sensor | C030 1/6.25" CMOS | Resolution | 480 TV lines |
| TV System | NTSC/PAL | Sensing area | 3.030*2.725mm |
| Sync System | internal | Video output | 1.0Vp-p, 75Ω |
| Minimum illumination | 0.5Lux | Electronic shutter | Auto |
| White balance | Auto | S/N ratio | Better than 40dB |
| IR LEDs | No | Lens angle | 85 degree |
| Video color | Colorful | Operation temperature | -20° ~+70° |
| Waterproof class | IP68 | Storage temperature | -30° ~+80° |
| Effective pixels | 640(H)*480(V) | Warranty | 12 months |
